Stainless Steel Y Type BALL CHECK VALVE for Air, Water, Beer Brew Dairy with Clamp Connection meet 3-A

Material:
SS304 and SS316L
Standard:
3A,SMS,DIN,Rjt,ISO
Connection ways:
Weld, Tri Clover, Nut, Thread etc.
Contact Now
Stainless Steel Y Type BALL CHECK VALVE for Air, Water, Beer Brew Dairy with Clamp Connection meet 3-A
EPDM gaskets Y-ball check valve
control flow check valve
preventing back flow Y-Ball check valve
Sanitary Y-Ball Check Valve
Buna Ball Standard Y-ball check valve
Stainless Steel Y Type BALL CHECK VALVE for Air, Water, Beer Brew Dairy with Clamp Connection meet 3-A

Product Description:

Specification 1.5''-4",  Y-Ball Check Valve , with an Air Blow Check Valve used together
Material SS304/SS316L
Standard 1.5''-4'' , can customize for you
Temperature range :  15°F to 195°F
Ball:  Buna (Standard) Tefon, Viton®
Max. Working Temperature  145 PSI
Availably connection Clamp / weld / thread
Finish:  Polish ID/OD to a 3-A Sanitary Finish, meet 3-A
Delivery details Usually within 20 days after receiving T/T down payment
Usage:  The working principle behind the Sanitary Stainless Steel Y-Ball Check Valve or Y-Body Check Valve begins  as liquid enters the run of the y-ball check valve, the ball lifts up into the branch, thus allowing full flow of product. Upon recession of flow, valve pressure equalizes, then the ball returns and resides near the smallest area of the run, preventing back flow. If a reverse flow situation arises, opposing pressure of the product will place the ball against the run of the valve preventing back flow whether the valve is in a horizontal or vertical position.
