Sanitary Stainless Steel Butterfly Valve with Kf End

The butterfly bodies are forged, the gaskets are subjected to 24 hour constant temperature treatment to ensure the high quality of the butterfly valve
Material:
SS304,SS316L
Standard:
SMS/3A, ISO/IDF,DIN,BS,RJT,ASME/BPE
Working Temperature:
VMQ(-50 to 180℃) EPDM(-20 to 135℃) FPM(-30 to 230℃)
Application:
Beer, Dairy, Beverage, Pharmacy, Cosmetics,
Connection ways:
Weld, flange, thread/union, clamped
Size:
DN15-150 and 1"-6"
Color:
Blue , black
Connection Type:
Wholesale and Retail
Surface Treatment:
inner(0.4-0.8µm) outer(0.8-1.6µm)
Pressure Value:
0-10bar
MOQ:
1pcs
Seal Material:
VMQ, EPDM,CMQ,FPM,silicone
Transport Package:
cartons
Sanitary Stainless Steel Butterfly Valve with Kf End
Sanitary Stainless Steel Butterfly Valve with Kf End Sanitary Stainless Steel Butterfly Valve with Kf End Sanitary Stainless Steel Butterfly Valve with Kf End Sanitary Stainless Steel Butterfly Valve with Kf End Sanitary Stainless Steel Butterfly Valve with Kf End Sanitary Stainless Steel Butterfly Valve with Kf End

Details

 Product Name:  Sanitary Stainless Steel Butterfly Valve
 Material:  SS304 or SS316L
 Standard:  3A, SMS, DIN, RJT, IDF
 Size:  1/2"-6" or DN15-DN150
 Connection Way:  Weld, Clamp, Thread (male/female) , KF
 Operated:  Manual, Pneumatic, Electric
 Manual Handle:  Pull Handle (2-4 Positions), Plastic Trigger Handle (13 Positions),
 Stainless Steel Trigger Handle (13 Positions)
 Seal Material:  Silicone, EPDM, Viton, NBR
 Surface Finishing:  Ra≤0.8
 Working Temperature:  -10 degree to +120 degree (EPDM)
 Working Pressure:  0.2-10 Bar (DN25-DN100), 0.2-8 Bar (DN125-DN150)
Application scope:  Dairy,food, beverage, pharmacy, cosmetic, Chemical, etc
 Packing Details:

Textile bag pack for each butterfly valve, two packed butterfly valves into one box,

 into cartons, then reinforced with a woven bag outside. Wooden box is also available

 depends on the quantity and the way of transport.
